Mallett Supercharged 2015 700+HP Colorado featured on Chevrolet Performance The Block

The folks at Chevrolet Performance’s The Block came by the shop to do a photo shoot and story about our 2015 Chevrolet Colorado back in 2016. They enjoyed our take on the Colorado so much, they ran it again this year.

Read the full story below.

For our final story of 2018, we’re looking back to a local Chevrolet Colorado here in Charlotte, North Carolina. This is not just any Colorado, but an intense racer set up with nothing in mind but quick lap times. It’s a four-seater pickup the owner tells us will pass C7 Stingrays at your local road course. We’re of course talking about Chuck Mallett, of Mallett Performance Cars, and his supercharged V6 Colorado with over 700 horsepower.

file

Mallett swapped in a 3.6L V6 from a 2016 Cadillac ATS-V due to that engine already being built for boost since forced induction was his desired path to horsepower success. The engine features a forged crank, titanium connecting rods and forged pistons. Bolted to the top is a Mallett Colorado Intercooled Supercharger Manifold assembly complete with a Magnuson 1.9L supercharger, custom 64mm C&R intercooler, custom CNC-machined upper and lower 8-rib pulleys, front engine idler pulley, tensioner mounting plate, drill-less mounted aluminum intercooler tank and water pump and C&R heat exchanger. Mallett used a C7 LT1 throttle body to open up the intake side and crafted a custom air intake box. Spent gasses are expelled through a custom high-flow dual exhaust, and let us tell you, it’s a true high flow as we breathed in the sweet nectar that is 109 race fuel while moving the truck in the parking lot during the shoot.

file

Power is nothing without getting it to the ground. Behind the V6 is a modified stock transmission that turns a narrowed Moser nine-inch rear-end with WaveTrac and aluminum center section. The rear differential then spins beautiful Forgeline custom MS3C concave wheels – 19×9.5 front and 20×13 rear – wrapped in rear 315/35/20 BFGoodrich G-Force Rivals. And spin they do — even with all that traction. Feathering the throttle just maneuvering the vehicle in a parking lot induced rear shrieks of euphoria from the sticky rubber.

file

To keep contact with the road and increase lateral stability, a lot of custom work was performed by Mallett and the team to the chassis and suspension. First, ride height needed to be adjusted to lower the center of gravity while maintaining correct geometry. Custom drop spindles were fabricated with custom lower control arms up front. Custom Penske coilover shocks were also installed. Out back, the rear frame section was raised and narrowed and a custom three-link ladder system with center frame crossbar and driveline hoops were fabricated and welded in. A custom rear sway bar and adjustable panhard bar were installed to fine tune the truck’s balance on track. Mallett knew his horsepower goals, his truck’s goal weight, and worked backwards from there determining the optimal wheel/tire sizing. Knowing the size of said rear tires, Mallett took to tubbing the truck bed some four-and-a-half inches wider each side, which as you can see in the photos, isn’t even noticeable due to pristine welding and paint.

file

How to Choose a Supercharger for Colorado / ZR2

We get a lot of questions about what makes our supercharger different from the other kits available on the market.

We get questions about our components: why do you use the 1900 TVS blower instead of the 1740 like other manufacturers?

We get questions about horsepower: why are horsepower claims by manufacturers so inconsistent? Some of them seem excessively high.

We have answers.

Continue Reading

2019 ZL1 Camaro Gets the Mallett Treatment

The Mallett Performance Cars team got back to our roots with this 2019 ZL1 Camaro project. When a customer is looking to add some power under the hood, they know that nobody brings the hammer down like Mallett.

Modifications include:

  • DOD Removal
  • LS7 Lifters
  • Mallett Performance Camshaft
  • CNC Ported Heads
  • 2650 Magnuson Supercharger
  • Kooks Long Tube Headers
  • Hi Flow Cats
  • 3″ Exhaust
  • 3200 RPM Stall Converter
  • 900+ rear wheel horsepower

Chevrolet Colorado Supercharger Battle: Mallett Performance vs Lingenfelter

The story below appeared on GM Authority on August 29, 2019, comparing the Mallett Performance Supercharger system to the proposed Lingenfelter tuning package.

Chevrolet Colorado Supercharger Battle: Mallett Performance vs Lingenfelter

BY JAKE STUMPH— AUG 29, 2019

Earlier this month, Lingenfelter announced a new supercharger kit for the Chevrolet Colorado ZR2. The highlight feature of that package is a major power bump for the 3.6L V6 LGZ engine, going from the stock 308 horsepower to 416 horsepower. That 35 percent bump in power is thanks to an Edelbrock supercharger.

Since then, GM Authority has taken to compare the supercharging kits, and spoke with Mallet Performance Cars – which was first to offer a supercharger solution for the Chevrolet Colorado and GMC Canyon way back in 2015. The North Carolina-based tuning firm has provided some interesting information that calls the Lingenfelter offering into question.

Mallett vs. Lingenfelter Supercharging Kits For Chevrolet Colorado & GMC Canyon

First, let’s compare the two kits. Both use Eaton-based superchargers, with Lingenfelter using a TVS R1740 while Mallett Performance using a TVS R1900. The numbers refer to the amount of air, in cubic centimeters, that the blowers push per rotation. Generally speaking, a smaller supercharger will have to be spun harder, using more boost to make as much power as a larger supercharger being spun at a slower rate and running on less boost.

The Mallett kit produces 361 horsepower and 332 pound-feet of torque at the wheels, and “that’s on a conservative, heat-soaked pull,” the firm tells us. Meanwhile, Edelbrock – which supplies the supercharger for the Lingenfelter kit, claims its kit is good for 345 horsepower and 306 pound-feet of torque at the wheels. The slightly lower power figure for the Edelbrock unit is understandable due to the smaller blower. However, Lingenfelter advertises 416 horsepower for its kit, presumably at the crank. As a result, it would seem that Lingenfelter is maxing out what that kit is reliably capable of.

And that is problematic, for a few reasons, the most noteworthy of which is that running more boost through a smaller supercharger tends to generate more heat, which can compromise durability and consistency. In fact, Chevrolet itself applied this very principle when sizing the supercharger for the 2019 Corvette ZR1 compared to the Corvette Z06.

“The key to engine longevity is intake temp and careful tuning”, Mallett tells us. The cool air being run through the TVS1900 used by Mallett keeps intake temps down. The company then adds Fluidyne intercoolers and a custom reservoir that holds roughly two gallons of coolant to stabilize those temperatures. That enables the Mallett system to “run wide open all day without any thermal issues.” Meanwhile, the Edelbrock 1740 in the Lingenfelter system will pull more heat into the air, while featuring a smaller reservoir. Hence, the kit will likely have trouble performing consistently when placed under heavy loads, such as being driven at high altitudes, towing, or towing at high altitude.

Of course, different dynos with different calibrations are going to produce different numbers, but the rest of the Lingenfelter kit seems to be on just as shaky of ground due to the drive belt. The Lingenfelter kit extends the standard five-rib drive belt to also drive the blower. That belt is perfect for driving the alternator and AC compressor, but its use in also powering the supercharger isn’t necessarily ideal, since an overburdened belt can quickly become the weakest link of an integrated system. If it fails, it can cause the entire truck to not run. By comparison, Mallett uses a bespoke eight-rib belt, with “the best idlers and tensioner in GM’s inventory and the best belt Gates makes.”

As an independent publication, GM Authority has no stake in the game, but when there are multiple aftermarket options available, buyers and bound to cross-shop. This is what Mallett Performance has told us thus far, but seeing that the Lingenfelter kit has yet to be released, the truth will out once it hits the streets. The only wild cards here are the price, with the Mallett kit coming in at $7,200. Pricing for the Lingenfelter kit has not yet been announced.

In the meantime, subscribe to GM Authority for more Chevrolet Colorado news, Chevrolet news and around-the-clock GM news coverage.

National Corvette Museum 20th Annual Hall of Fame Induction Ceremony

Chuck travelled to the National Corvette Museum in Bowling Green Kentucky for the 20th annual Hall of Fame Induction Ceremony.
He was invited there to honor his friend and long time racing companion Jim Minneker and Tommy Morrison of the Morrison Motorsports Corvette/Mobile Endurance Racing Series.
Jim Minneker was the Engineering Group Manager for GM High Performance Vehicle Operations. Starting in 1996, Chuck and Jim competed in The One Lap of America multiple times, co-driving Mallett Motorsports modified Corvettes in the events.
Pictured here is the Mallett Motorsports Corvette ZR1 monster race car. It was equipped with a 396 CI splayed value engine using a custom intake system, dry sump lubrication, and a Paxton Novi supercharger with methanol water spray that generated 1449 horsepower, with top speeds over 249.
This car was featured in a story Trash to Flash Nov 1996 Corvette Fever Magazine.
Pictured here left-to-right are Chuck Mallett, Dave Sarafian, and Jim Minneker in Wisconsin heading to their next One Lap event at Road America Racetrack.

Chuck and Jim co-drove the Mallett Motorsports C-5 pictured below the next year in the 1997 One Lap of America race. Under the hood was an untested Z06 engine that would not be released by GM until 2001. This Vortec supercharged LS6 engine produced 600hp that offered drivability and excellent mpg at low speeds, made possible by an M12 6-speed and 3.42 rear end.

A Mallett/Penske coilover suspension combined with Alcon 13.5 slotted disc brakes using 6-piston front and 4-piston rear calipers and PFC pads provided solid handling. This Mallett creation was in a league of its own, running 1/4 mile in 11:30.

The team finished in 2nd place overall in a field of over 180 entrants.

Chuck and his brother Lance raced as part of Hall of Fame inductee’s Tommy Morrison Corvette Endurance team from 1983-1996.

They were instrumental in building and modifying the 1989 ZR1 that broke a 50-year-old 24-hour average speed record. The team averaged 175.8 mph.

The team raced successfully at Daytona, Sebring, Watkins Glen, Road America, and many others.

A great time was had by all honoring the lifetime of achievements by these men. Pictured below left-to-right are: Dr Don Knowles, John Heinricy, Jim Minneker, Chuck Mallett, Dave Ridgeway, and seated is Tommy Morrison.

Pictued below left-to-right: John Strazinskey, Lance Mallett Dave Ridgeway, Chuck Mallett.

Mallett Cars Debuts 2015 Chevrolet Colorado Supercharger Kit at SEMA 2015

The 2015 SEMA show kicked off at the Las Vegas Convention Center November 3 through Friday November 6.

The Mallett Performance Cars team was on site in the Magnuson Superchargers booth, debuting our new tested and tuned supercharger system for the 3.6L 2015+ Chevrolet Colorado/GMC Canyon.

The Supercharger kit is the first of its kind and was designed, fabricated, and installed at Mallett Performance Cars’ shop in North Carolina.

See the complete specs below.

2015 Chevy Colorado 3.6L V6 Intercooled Supercharger Kit

  • 2015 Mallett Chevy Colorado Intercooled Supercharger Assembly Kit
    • Dyno-Tuned for Optimum Performance and Reliability
    • Extremely Drivable with Smooth Consistent Power Gains Throughout the RPM Range
    • 100+ Rear Wheel HP and 100+ RW Torque Gains over stock performance – more power than a stock V8 Silverado
    • Highest Quality US-Manufactured Components:
      • Proven Eaton TVS 1900 Rotor
      • Genuine GM Tensioner and Steel Idlers
      • High-Efficiency Intercooler and Heat Exchanger
      • CNC-Machined Pulley Assemblies, Hard Coat Anodized
      • Fleet Quality 8-Rib Gates Supercharger Belt
      • High-Strength, Corrosion Resistant Fasteners
      • 2-Gallon Custom Aluminum High-Volume Reservoir
      • Performance Tune Included with Purchase of Supercharger
      • Detailed, Fully-Illustrated Color Manual
  • Bolt-On Application for Experienced DIYers

UPDATE: You can buy yours today by clicking here.
